MATERIAL OVERVIEW
Properties to guide your selection.
A tough thermoplastic offering a useful balance of impact resistance and resistance to selected chemicals. Its low tendency to warp supports functional prototypes and general-purpose printed components.
Selection considerations
Check compatibility with the actual chemical and operating temperature.
Discuss this material →| Printing process | FDM |
|---|---|
| Supplier-listed dimensional accuracy | ±0.3mm |
| Listed colours | Black/White/Red/Blue/Yellow/Green/Purple |
| Tensile strength | 53MPa |
| Tensile modulus | 3000MPa |
| Elongation at break | 31% |
| Flexural strength | 171MPa |
| Flexural modulus | 2040MPa |
| Heat deflection temperature | 68°C |
Heat deflection temperature is a test result, not a continuous-use temperature. Dimensional requirements are reviewed against the drawing.
