MATERIALS / FDM
PAHT-CF
High-temperature nylon composite
← Back to material selection
MATERIAL OVERVIEW
Properties to guide your selection.
A carbon-fibre-reinforced, high-temperature nylon formulation for demanding functional components. The supplier positions it around strength, thermal performance and resistance to selected chemicals.
Selection considerations
Verify the exact nylon grade and operating conditions.
Discuss this material →| Printing process | FDM |
|---|---|
| Supplier-listed dimensional accuracy | ±0.3mm |
| Listed colours | Black |
| Tensile strength | 106.69MPa |
| Tensile modulus | 6.54GPa |
| Elongation at break | Not specified |
| Flexural strength | 132.50MPa |
| Flexural modulus | 4.68GPa |
| Heat deflection temperature | 194.6°C |
Heat deflection temperature is a test result, not a continuous-use temperature. Dimensional requirements are reviewed against the drawing.
